Crawler Cranes - 2200E

Sennebogen Cranes

2200E Crawler Crane

Lifting Capacity : 80t
Boom height : 67.2m
Engine capacity : 186kW
Winch : 85kN


  • CAT diesel engine C7 with direct injection
  • water-cooled
  • 186 kW (253 HP) at 2000 rpm
  • Dry air filter with main and safety element.
  • Electric system 24 Volt, high efficiency cold starting batteries.
  • Idling speed function.
  • Fuel tank capacity approx. 800 l


All hydraulic pumps are variable displacement piston pumps with individual regulation for each pump. The pumps are equipped with an energy-saving flow-ondemand control system and pressure cutoff for high efficiency and reduced loss of energy.

Max. flow rates:

  • 300 l/min for travel and winch 1
  • 300 l/min for travel and winch 2
  • 200 l/min for boom hoist
  • 200 l/min for swing

Working pressure up to 330 bar. Hydraulic tank capacity approx. 900/710 l
Hydraulic oil filters with long intervals between change. Large dimensioned hydraulic cooling system. Servo-assisted joy-stick controls according to ISOSystem. Central service tableau. Decomposable hydraulic oil (synthetic) can be used. Hydro Clean hydraulic superfine filter with water absorption (optional).

Winch 1 - Winch 2

Each winch is driven independently by a directly flanged variable displacement hydraulic piston motor with high pressure regulation. Hydraulic brake valves for wear resistant braking of loads. Strong low maintenance oil bath planetary gears. The clutch and brake functions are effected through large dimensioned, maintenance-free, low-wearing, oil-lubricated multiple disc brakes. Grab closing automatics for 2 rope grab operation – dividing the load equally between both winches.
Winches 85 kN max. Single Line pull kN 1. Layer 120
Rope dia. mm 22
Line speed m/min 120
Optional: Additional crane winch

Swing drive 360° endless

The swing function is completely independent operated by a separate hydraulic circuit through 2 swing drives each with hydraulic piston motor and oil bath planetary gear. Spring-loaded hydraulically releasable multiple-disc brake, self-closing. Swing speed from 0 to 4,0 rpm, 0 to 2 rpm for crane operation. Precision swing operation. Large dimensioned swing bearing, external gears thus less tooth pressure and moments.

Boom Hoist Operation

Completely independent operation by a separate hydraulic circuit via axial piston motor, spring-loaded hydraulically releasable multiple-disc brake, planetary gear and winch drum with special scores. Max. line pull 45 kN (4,5 t). Drum pawl lock provides an integral drum lock.

Upper Structure

Torsion-free precision machined upper frame. All components are located clearly and service friendly. Engine installation very service-friendly in longitudinal direction with low noise level. Counterweight 25 t


Strong hydraulically extendable crawler undercarriage. Each track is independently driven by an axial piston motor through planetary final drive. Spring loaded hydraulically releasable multiple-disc brake. Maintenance-free tractor type crawler with hydraulic track-tensioning device. Tractor type crawler with triple bar shoes. Excellent rough terrain travel. Travel speed with crawler B7 is 0 – 2,1 km/h.
Optional: Flat shoes

Working equipment

Tubular boom 12,1 – 59,7 m, double sheave hammer head, fixed jib, auxiliary jib. Complete crane safety device with electronic SLI-safe load indicator. Various range of additional equipment on request.

Operators cab

Comfortable F 2000 operator’s cab, resiliently mounted, with exceptional sound suppression, large-capacity compartment with excellent allround visibility, all-weather design with tinted safety glass, front wind-screen with ventilation position stows under the roof, large-size skylight, window wiper/ washer system for front windscreen and skylight, front guard panel, large-capacity stowage rack, ergonomically designed comfortable seat, resiliently mounted, adjustable in suspension and height, seat cushion adjustable in depth and angle, adjustable lumbar support, wide adjustable armrests, clearly laid out instrument panel with ergonomically shaped control levers, adjustable steering column (mobile machines only), infinitely variable cab heating system, outside air and circulating air stages, with particle filter. Five adjustable air vents for optimum work environment, new SDS diagnostic system for monitoring of all essential machine and engine functions, includes visual and audible warning of any malfunctions. Wide range of additional features and equipment.

Service weight

Base machine 2200, 2 x 85 kN winches, 186 kW diesel engine, 12,1 m basic boom, counterweight 25 t
crawler B7, 700 mm triple bar shoes:

approx. 72 t

* Further details see adobe specifications download or please contact PACECRANES.
† Due to improvements, the specifications are subject to change without notice.
